Currently this is pick-up only from an Auckland Location, you are welcome to organise your own freight we have provided packed dimensions below.
Your car deserves the best, and that's exactly what our premium aluminium carport delivers. At Container Door, we're not just getting started with aluminium structures—we're pros. We've sold over 8,000 aluminium pergolas across New Zealand, so when it comes to quality and design, we know our stuff. Now, we're taking all that expertise and moving on to carports, bringing you the same top-notch craftsmanship and sleek style.
Keep your vehicle protected with our premium aluminium structure, designed to withstand the elements while looking sleek in any driveway.Our 6-metre long solid aluminium beams are engineered for exceptional strength and structural integrity. Unlike beams with multiple joins or sections, these continuous solid beams provide durability and load-bearing capacity.
The overall dimensions for this carport is 6.05m Long, 6m Wide and 2.45m high (at its highest point).
The carport’s highest point is at the entrance, which stands at 245cm on the 600cm side. Over the 605cm length, the height gradually slopes down by 15cm to 230cm at the back, ensuring water flows away from the entrance. For added support, an extra leg is positioned in the middle at the back of the carport. The aluminium panel roof features an interlocking corrugated system to also prevent leakage.
A carport is great for protecting your car—until it becomes the perfect spot for BBQs, home gyms, or an impromptu dance floor!
Want more than just a roof? Opt for panelled sides (sold separately) to add shelter from wind and rain—or simply to enhance the look of your space.
Available in 3 Matte Colour:
Black
Grey
White
Overall Dimensions:
605cm x 600cm x 235 - 245cm (L x W x H)
Clearance (from base plate to top of under top beam):
Clearance on the lowest point: 215.29cm
Clearance on the highest point: 229.69cm
Specifications:
Full Aluminium Construction
Post Dims: 120 x 120 x 2mm
Side Beam Dims: 120 x 85 x 1.5mm
Middle Beam Dims: 100 x 50 x 3mm
Gutter Dims: 100 x 45 x 1.5mm
Base Plate Dims: 180mm, 120cmm post.
Includes: 12 x roof panels that are 315 cm x 100cm (L x W)
Distance between the legs on the 605cm side is 185.65cm
Distance between the legs on the 300cm side is 184cm
Installation
Firstly, we do recommend that you have your carport professionally installed, simply because it is a large beast. These need to be installed on professionally laid concrete slab or concrete footings with a depth of 150mm at the bare minimum.
The screws provided are intended for use in a sheltered domestic back-yard-type situation only. For exposed or wind-prone area, we again recommend getting professional assistance. You will also need to obtain suitable fixtures (not provided). Alterations to your carport will void warranty.
Warranty Exclusions:
Warranty does not cover fading or damage incurred due to extreme weather exposure (including heavy rain, winds, exposure to high heat from bbqs and heaters).
It also does not cover damage to the carport caused by negligence, accident or misuse. If near coastal areas, please maintain your structure and wash it from time to time to avoid corrosion.
Please follow the instruction manual for installation as damage caused by not following the instructions will void your warranty. Warranty covers domestic use only and does not apply to commercial use. However, we will do our best to help with any issues or replacements parts.
Packed Dimensions (mm):
Box 1:2500*275*260mm------------33.6kgs
Box 2:2450*390*140mm------------32.5kgs
Box 3 :2350*275*140mm------------16kgs
Box 4 :5870*170*135mm-------41.3kgs
Box 5 :5870*140*185mm-------44.2kgs
Box 6: 5950*200*190mm-----------38.5kgs
Box 7: 5950*200*190mm-----------38.5kgs
Box 8: 3200*1100*100mm---- 56.5kgs
Box 9: 3200*1100*100mm----56.5kgs
Box 10:300*220*220mm--19.5kgs
