Flat-Rate Delivery Available For Both North & South Island (see corresponding North or South Island Deal)
This New Zealand-made carport is ideal for creating stylish shelter for your wheels. So if your parking area looks a little forlorn and you’re tired of leaving your trusty chariot or boat & trailer exposed to inclement elements, look no further. This model is a medium length and standard width single carport.
Streamline Carports are all constructed in NZ from premium quality steel and a strong PurlinDek roof. These carports are fully engineered to withstand New Zealand conditions and comply with New Zealand codes. They come with a 10 year manufacturer’s structural guarantee and there’s likely to be no consent required – except perhaps from your significant other - as they're under 30m2.
If you’re going to pour a fresh tar-seal and embed the posts, please read the instructions about minimum requirements. And if your concrete pad already exists you’ll need to buy one base plate for each post /leg (see our other deal).
Coloured Steel: $4499
- Grey Friars
All elements share the same colour – roof, guttering, posts etc.
For a closer look at the Colorsteel colours, click CLICK HERE. For Black refer to their Ebony colour.
Note: These carports are built to last and are backed by a 10 year manufacturer warranty, however if carport is situated within a location where sea spray may come into contact, then we do advise regularly hosing/washing down carport so as to ensure the longevity of the finish/paint.
General Technical Information
Yes, you can attach the carport to the side of a house:
However the attachment method and what the Streamline Carport is attached to will need to be checked by and engineer.
Yes, you can install the carport onto an existing concrete driveway:
There are two ways to accomplish this:
1. Cut holes for the posts through the concrete and install posts into the 900mm deep hole with concrete.
2. Purchase Top Mount Feet and Dyna Bolt these to the existing concrete. THESE ARE SOLD SEPARATELY - please see our other deal. You will need 4 x Top Mount Feet for this size.
For assembly and care instructions: CLICK HERE
For technical information on PurlinDek roofing CLICK HERE
Model: Single Carport, extra length, standard width SC5430
Size: 5.45 x 3m (L x W)
New Zealand made 10 year manufacturer’s structural warranty
Made from high quality steel
Rivet gun and a drill required for assembly – not provided .
4 x posts
3m high – if embedded they stand 2.1m tall
0.75 roll-formed BMT steel (base metal thickness)
Clearance distance between posts is 360mm less than width dimensions
Maximum span between posts down the length of the single carport is 4.2m
N.B. If choosing the zinc option, the posts are galvanised. If choosing the coloured steel option, the posts match the colour of the roof top.
0.40g BMT gauge iron features on spans up to 3m
0.75g BMT gauge iron features on spans of 3m to 6m between purlins
Maximum overhang of gutters over post is 850mm
Coloured steel or zinc finish on the top surface, grey primer underneath
Guttering on all four sides
Slope - 25mm slope minimum for single carports, 100mm for doubles.
• PurlinDek roofing
• Gutter beams
• Fascia beams
• Steel posts
• 3m Downpipe – 65mm
• Bolts, nuts, washers, rivets
• PVC dropper & clip
• 300g Silicone
• 125ml touch-up paint
• Black seal and brush
• 3/16 drillbit
